i2s straight to Dclass

i2Dclass

i2s direct to Dclass audio

WHAT IS
i2Dclass?

A completely new take on decades-old technology.

i2Dclass is a single stage conversion technology that converts serial audio data (i2s, AES3, SPDIF etc) directly into Dclass outputs for professional grade analog audio - without the need for costly interim conversions, tuned multibit outputs, or large heatsinks.

KEY BENEFITS

LOW COST & PART COUNT

Only a handful of parts are necessary to produce professional grade audio for mass market applications. Even the heatsink can be discarded up to 80Wrms a channel.

SINGLE BIT OUTPUT

Natively compatible with a variety of existing bridges or discrete part solutions, and inherently linear- no messing about with multi-bit/Low Pass Filter (LPF) stages, re-encoding, etc...

LOW SWITCHING FREQUENCY

Output switching frequency (Fsw) low enough to drive D-class/power inverters directly- no interim costly and noise inducing filtering, buffering and remodulation.

ULTRA LOW PROPAGATION DELAY

25us including deserialization, PCM to one bit conversion, AND output filter. Enables ultrasonic noise cancellation, no latency gaming etc.

OPEN LOOP

Allows ‘analog’ volume control by varying output voltage without bit shifting, maintaining dynamic range (no lost bits due to shifting)

EMBEDDED PROTECTION

Real-time Over Current Protection (OCP) incorporated with the DAC provides terminal short circuit protection for any voltage and power.

Do any of these sound too good to be true?

We have an affordable, reliable, DELIVERABLE single chip solution in retail products NOW!

EXISTING TECH CHALLENGES

The goal

Converting digital signals to high power analogue is much harder than most appreciate.

The ideal

New high resolution digital audio formats promise unprecedented levels of clarity- reproduction is the challenge.

The limits

Despite best endeavours, trade-offs are made in cost, size, quality, efficiency, and time to market.

The best intentions

Dclass output stages are far more efficient that traditional analogue amplifiers, but at the cost of sound quality

APPLICATIONS

Power/size restricted

Low cost and incredible power density is perfect for power and or size-restricted devices

PoE | Battery | Solar | Portable | Motorcycles | Headphones

Low latency

Microsecond delay is ideal for real time sensitive applications

Gaming | Medical | Noise cancellation

Performance

Performance and High definition audio

HD audio | PAs | EVs | Monitors | Studios | Concert venues

Introducing

NXIAVA2

The first IC to contain the i2Dclass technology- samples and volume quantities available now.
